Solar Pump System with Energy Storage

INTRODUCTION This solar water pump system which designed excellently by SolarPumpSys is composed of solar cell array, soalr water pump inverter, AC water pump, water storage device and AC powerpack,etc. It uses solar energy as power source to directly draw water from deep wells, rivers, rivers, lakes and other water sources through water pumps.When the sunlight intensity becomes weak, the solar water pump system can also realize the switching function of the electricity supply like Utility or diesel generators, and the electricity supply can real-time and online sharing the energy from the solar and Utility or diesel generators.

INTRODUCTION This solar pump system is composed of solar cell array, soalr water pump inverter, AC water pump, water storage device and AC powerpack,etc. It uses solar energy as power source to directly draw water from deep wells, rivers, rivers, lakes and other water sources through water pumps.

1.IP68 junction box and connector have a high degree of waterproof, effectively resist the harsh environment 2.The junction box carries a current of 15A, ensuring high current flow through the modules 3.Glue-spilled tank has a double-layer waterproof, cross-section with hook-shaped aluminum frame, enhanced by 10% of the mechanical load strength 4.The module refines the current division, thus effectively reducing the loss of up to 2% due to mismatch and increasing the power output of the system 5.Excellent salt spray resistance, anti-ammonia and anti PID, TUV, SUD certification approved 6.Passed the 2400pa wind load and 5400pa snow load test, ensuring that the module has a stable mechanical life 7.Modules are packaged according to color classification, to achieve consistent appearance after installation

1.Assembled with multi-busbar PERC cells,the half-cell configuration of the modules offers the advantages of higher power output,reduces BOS cost effectively; 2.Special half-cell design reduces the energy loss caused by shadows,better anti-shading performance; 3.Lower hot spot risks due to half-cell layout,offers an additional level of safety; 4.1500V DC voltage of the system,reducing the cost of the system side; 5.The overflow tank is waterproof with double layers,and the cross section contains hooked aluminum frame,which enhances the mechanical load strength by 10%; 6.Passed the certification test of 5400 Pa snow load and 2400 Pa wind load;

System application: Solar pump system is mainly used in the fields of daily life water, agricultural and forestry irrigation, desert management, livestock water, village and town water supply, sewage treatment engineering and fountain landscape.

Solar pump inverter obtains direct current energy from photovoltaic cells, and converts it into electric energy to drive the water pump. According to the intensity of sunlight, take use of MPPT algorithm, the inverter adjusts the output frequency to make maximum use of solar energy.

Assembled with multi-busbar PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk of hot spot, as well as
