Support MPPT function
Brand:
SolarpumpsysPayment:
FOBProduct Origin:
Hefei Anhui ChinaColor:
WhiteShipping Port:
Nanjing, Ningbo, Shanghai，Shenzhen，GuangzhouLead Time：
7 days
Feature:
1.Wide battery voltage range
3.Support MPPT function
| Model | JNS20K-A-V1 | JNS30K-A-V1 | JNS60K-A-V1 | JNS120K-A-V1 |
| PV Input |
|
|
|
|
| Max. PV array input voltage | 800Vdc | 800Vdc | 800Vdc | 800Vdc |
| Recommended PV Module Configuration | 2 channels, each channel 4 in parallel and 13 in series 330Wp, total 34320W | 2 channels, each channel 4 in parallel and 13 in series 330Wp, total 34320W |
and 13 in series 330Wp, total 34320W 2channels，each channel 8 in parallel
and 13 in series 330Wp,total 68640W
|
4channels，each channel 8 in parallel and 13 in series 330Wp,total 137280W |
| MPPT voltage range | 250~750Vdc | 250~750Vdc | 404~750Vdc | 404~750Vdc |
| Battery |
|
|
|
|
| Rated voltage | 230Vdc | 230Vdc | 384Vdc | 384Vdc |
| Type | Gel/lithium | Gel/lithium | Gel/lithium | Gel/lithium |
| Max. charge current | 150A | 150A | 150A | 300A |
| AC output parameters (on grid) |
|
|
|
|
| Grid voltage range | 304Vac~485Vac | 304Vac~485Vac | 304Vac~485Vac | 304Vac~485Vac |
| Grid voltage frequency | 50/60Hz (±5%) | 50/60Hz (±5%) | 50/60Hz (±5%) | 50/60Hz (±5%) |
| Voltage standard | 3-phase 4-wire，3W+1PE | 3-phase 4-wire，3W+1PE | 3-phase 4-wire，3W+1PE | 3-phase 4-wire，3W+1PE |
| Rated voltage | 400Vac(380/400/415Vaccan be set) | 400Vac(380/400/415Vaccan be set) | 400Vac(380/400/415Vaccan be set) | 400Vac(380/400/415Vaccan be set) |
| Rated power | 20kW | 30kW | 60kW | 120kW |
| Total harmonic distortion（Ithd） | ＜3% | ＜3% | ＜3% | ＜3% |
| Power factor | >0.99 | >0.99 | >0.99 | >0.99 |
| DC output parameters (off grid) |
|
|
|
|
| Rated output capacitor | 20000VA | 30000VA | 60000VA | 120000VA |
| Rated output power（linear load） | 20000W | 30000W | 60000W | 120000W |
| Rated voltage | 400Vac(380/400/415Vac can be set) | 400Vac(380/400/415Vac can be set) | 400Vac(380/400/415Vac can be set) | 400Vac(380/400/415Vac can be set) |
| Grid voltage frequency | 50/60Hz (±5%) | 50/60Hz (±5%) | 50/60Hz (±5%) | 50/60Hz (±5%) |
| Voltage standard | Three-phase five-wire, 3W+1N+1PE, single-phase output capacity :30% rated power | Three-phase five-wire, 3W+1N+1PE, single-phase output capacity :30% rated power | Three-phase five-wire, 3W+1N+1PE, single-phase output capacity :30% rated power | Three-phase five-wire, 3W+1N+1PE, single-phase output capacity :30% rated power |
| Total Harmonic Distortion（Vthd） | <3% | <3% | <3% | <3% |
| Overload | 1min@≥120% load;10min@ 110%load | 1min@≥120% load;10min@ 110%load | 1min@≥120% load;10min@ 110%load | 1min@≥120% load;10min@ 110%load |
| Other |
|
|
|
|
| Autible noice | <62dB | <62dB | <62dB | <62dB |
| Protecition level | IP21 | IP21 | IP21 | IP21 |
| Cooling method | Forced cooling | Forced cooling | Forced cooling | Forced cooling |
| Operate temp. | -20～+55℃ | -20～+55℃ | -20～+55℃ | -20～+55℃ |
| Storage temp. | -25～+70℃ | -25～+70℃ | -25～+70℃ | -25～+70℃ |
| Status indicator | LCD+LED | LCD+LED | LCD+LED | LCD+LED |
| Interface | RS485 | RS485 | RS485 | RS485 |
| Elevation | 2000m(>2000m derating operate) | 2000m(>2000m derating operate) | 2000m(>2000m derating operate) | 2000m(>2000m derating operate) |
| Dimension(W*D*H)(mm) | 600*781*1300 | 600*781*1300 | 600*781*1600 | 600*781*2000 |
| Weight (kg) | 240Kg | 240Kg | 290Kg | 360Kg |
Solar off grid power system is composed of PV module, Solar Off grid inverter, and Battery pack.it converts DC power produced by solar panels to AC power to provide electric energy for applications. MPPT charge controller charge the solar electricity into batteries. When solar energy is not enough for loads, or at night, the battery pack will be discharge to replenish energy for loads.
Solar pump inverter obtains direct current energy from photovoltaic cells and converts it into electric energy to drive the water pump. According to the intensity of sunlight, taking use of the MPPT algorithm, the solar pump inverter adjusts the output frequency to make maximum use of solar energy.
Solar pump inverter obtains direct current energy from photovoltaic cells, and converts it into electric energy to drive the water pump. According to the intensity of sunlight, take use of MPPT algorithm, the inverter adjusts the output frequency to make maximum use of solar energy.
It is suitable for agricultural irrigation, pool water supply, animal husbandry and rural water supply
This solar pump inverter input of the utility grid/DG and photovoltaic, automatic switching, online energy complementary,photovoltaic priority, keep the pump rated work, and achieve 24H water supply
Application: Areas without electricity, low power,unstable power grids,and high electricity prices where solar air conditioner is in demand.
Solar water treatment is a type of portable water purification that uses solar energy to make biologically-contaminated water clean. ... One method for solar water disinfection (also called SoDis) uses solar energy to make water contaminated with bacteria, viruses, protozoa and worms safe to drink.
Solar pump inverter obtains direct current energy from photovoltaic cells, and converts it into electric energy to drive the water pump. According to the intensity of sunlight, take use of MPPT algorithm, the solar pump inverter adjusts the output frequency to make maximum use of solar energy.
